NEXA - 316 - 16

AWS/SFA Classification: Stainless Steel Electrode

Request Quote

Applications

  • check_circle Welding Mo bearing austenitic alloys represented by AISI 316, 317 types
  • check_circle Welding of equipments in Chemical, Paper and pulp, Paint and dye industries
  • check_circle Cladding stainless steels
  • check_circle Suitable for material no. 1.4401 & similar grades

Characteristics

  • check_circle Rutile type coating
  • check_circle Weld deposit with 19/12/Mo
  • check_circle High resistance against intergranular corrosion
  • check_circle High welder appeal
  • check_circle Offers improved corrosion and pitting resistance in marine and industrial environment
  • check_circle Radiographic quality weld

Typical Weld Metal Chemistry (%)

C Mn Si Cr Ni Mo
0.08 max 0.5-2.5 1.0 max 17-20 11-14 2-3

Mechanical Properties

UTS (MPa) El%
>520 >30

Welding Parameters AC (70 OCV) /DCEP

2.50mm x 350mm 3.15mm x 350mm 4.00mm x 350mm
50-70 70-100 110-140

Packaging

  • inventory_2 10 KG Carton, 5 Vacuum Packed Packets of 2KGs Each
